iC7-Automation Air-cooled Enclosed Drives
Operating Guide

10.8.5 Protections

Table 54: Protections
Item
Overvoltage trip limit
Undervoltage trip limit
Ground fault protection
Mains supervision
Motor phase supervision
Overcurrent protection
Unit overtemperature protection
Motor overload protection
Motor stall protection
Motor underload protection
The motor overload protection activates at 110% of the full load current.
1

10.8.6 Product Compliance

Table 55: Product Compliance
Item
Conformity
Safety standards
Functional safety
Marine type approvals

10.8.7 Efficiency

Table 56: Efficiency
Item Technical data
Efficiency Inverter module >99%, AFE module + LCL filter 97.5%, FE module 97.1% at 500 V AC, 1.5 kHz
110 | Danfoss A/S © 2023.09
Technical data
Mains voltage 500 V AC: 911 V DC
Depends on mains voltage (0.8775 x mains voltage)
Mains voltage 400 V AC: trip limit 334 V DC
Mains voltage 500 V AC: trip limit 447 V DC
Yes
Yes
Yes
Yes
Yes
Yes
(1)
Yes
Yes
Technical data
CE, RCM, KC, EAC, UA, UKCA. See the product label of the drive for more approvals.
IEC/EN 61800-5-1 + A1
IEC/EN 62477-1 + A1
–
–
Specifications
AQ330347384398en-000201 / 139Z8096
