Function Variants

6 Function Variants
Standard configurations can be activated on the DISOMAT (they are what are known
as 'function variants'). They provide all inputs and outputs including the function
process needed for carrying out typical or frequent scale jobs.
The sections below describe how to operate and set the function variants
•

DISOMAT F

•
Filling Scale
•
Discharge Scale
•
Crane Scale
•
Cargo Scale
•
ZEUS Road Weighbridge
•
Fieldbus-IO
•
Disoplan
6.1 DISOMAT F
This type of function activates compatibility to the predecessor DISOMAT F.
The DISOMAT F has not provided the properties given with (N).
Buttons:
F1 Printing
Inputs:
In 1: Taring
In 2: Clear tare
In 3: Zero positions
In 4: Quit event (N)
Outputs:
Out 1:
Out 2:
Are driven by the fieldbus (N)
Out 3:
Out 4:
®
