Setting Mode
Definitions
For better understanding, some terms shall be explained.
Term Definition
Form format Editable string whose contents determines the sequence of printout.
Format element Part of a form format (format variable, special character, additional
text). Format elements are separated by commas (max. 20 digits
between 2 commas).
Format variable A symbolic name standing for the format element to be output (e.g.
'BZ' for string).
Form text Editable string whose contents can be output through the format
variable in the form of 'Sn' (n=1,2,3). A form text is part of the form
format and is but seldom changed, e.g. company name.
Editing - Some Rules
When changing form format, observe the following rules:
•
Ensure that codes are separated from one another by comma.
•
Ensure that form format line length does not exceed 200 digits (including
commas).
•
Ensure that the balance of all formats (i.e. incl. EDP Format) does not exceed
1000 digits.
•
For editing inputs, observe the instructions given at Item 3.4.2 'Data
Input/Output'.
For details on codes used, see Code Table.
Additional Texts
If you need more form text, simply add additional text to form format. Position text
between two commas (max. 20 digits between 2 commas).
Example: You wish to print text "SCHENCK scale with DISOMAT". Coding in form
format is: 'SCHENCK scale, with DISOMAT' (see example below).
Attention: If the text between two commas exactly matches a code, this text, too, is
interpreted as code; this means that letter 'B' cannot be output alone being reserved
for a code symbol and interpreted as prompt for output of Gross weight. However, text
'Gross' can be output being interpreted now as text and not as code.
Operating Sequence
First go to input field and enter number of form format to be edited (admissible
values: 1 to 6), e.g.
462:Form Formats
Form Format 1
Operate [ENTER] key, and input line displays current string. e.g.
462:Form Formats
Form1 P1,D,P10,U,P18,LN,P27,BZ,P40,B,T,N,F1
Change coding to your requirements and acknowledge with [ENTER] key. Selected
format is programmed.
