Setting Mode
Code Description
RU2 Output time when second weight transferred to format conversion has been
recorded
S Output setpoint
SC Output number of dumps
SNR Output material number
Sn Output form text (entered at item '461:Form Texts');
n = 1 ... 3;
T Output current Tare weight value; printer output, e.g.: 123.45kg T;
U Output current time, e.g.: 23:59
Yn Output <n> line feeds on printer; n = 1 ... 99;
Y2, e.g., creates 2 line feeds.
Addition of ":dd" to the code variable (e.g. BZ:4) limits the output to the left "dd" digits
of the variable contents.
This replaces to a limited extent the previous possibility to reposition printer output
using Pxx (no longer possible from Version 07).
":dd" has NO influence on code variables B, T, N, NE and LN relevant for certified
applications.

5.2.1.3 Fct. 463:Page Header Format

Use menu item to match current page header format.
ATTENTION: Function '469:Load Default Text' replaces your changes by the
default settings.
After form feed, a page header is output on printer on top of every page. This is of
advantage if your printout covers more than one page.
A new page starts if
•
function '34:New Page' is executed via menu tree
•
code 'Fn' is output via form format
•
internal line counter set by parameter 'Page Lines' has reached set value
(see function '4332:Printer').
Line counter is reset to value '1'.
Operating Sequence
After start of function, input field for presetting of header text format for output in list
form opens:
463:Page Header Format
Page Header Format Y5,P1,S1,P27,S2,P40,S3,Y2___
You can use the formatting codes described with function '462:Form Formats'.
Example: See function '468:Load Default Form'.
®
