Setting Mode

5.2.1.1 Fct. 461:Form Texts

For creation of image, the '462:Form Formats' function uses various codes. Using
code 'Sn' (n=1,2,3) one of three form texts can be inserted.
Form texts are preassigned as default. If other texts are required, you can match
these to your requirements using the described functions, and reload the default
settings at any time (see function: '469:Load Default Text').
Operating Sequence
Input field for first form text opens, e.g.
461:Form Texts
1st Text: Date____Time_______Cons.No.____
If need be, enter string and/or go to second or third form text using the [ENTER] key.
461:Form Texts
2ndText: Veh.No._______________________
461: Form Text
3rd Text: Weight___________________
Acquire changes with [OK] key.
Note: If you need more form texts, simply add text to form format (see '462:Form
Formats').

5.2.1.2 Fct. 462:Form Formats

The form formats below correspond to relevant function block and menu tree
functions:
Form Format
Form Format 1 Print1
Form Format 2 Print2
Form Format 3 Print3
Form Format 4 Print4
Form Format 5 Print5
Form Format 6 Print6
You can match these form formats to your requirements using the function described
here.
You can, e.g.
•
Change form division
•
Determine weigh data to be printed, e.g. Gross, Net, Tare, Balance)
•
Determine additional texts to be printed.
Tip - You can output the stored system formats using menu item '56:Print
Parameters'. With the aid of the printout, changes are easier to perform.
NOTE: If no changes have been effected, system uses its default formats (see
function '468:Load Default Form').
®
DISOMAT Opus – Operating Manual
© Schenck Process GmbH, Darmstadt
Setting Using Parameter Password
Function Block Menu Tree Function
'31:Print 1'
'32:Print 2'
'33:Print 3'
'36:Print 4'
'37:Print 5'
'38:Print 6'
