Setting Mode

5.4.2 Fct. 441:Calibration Parameters

The calibration parameters determine the scale characteristics. Changes at
this menu item are possible only if
•
calibration has been prepared as described at Item Fct.
44_SCALE and
•
calibration password has been entered.
After any change to calibration parameters, recalibration may be
necessary.

5.4.2.1 Operating Sequence

Use DIRECTION KEYS to go to menu item
441:SCALE
Calibration Parameters
and acknowledge with [ENTER] key.
Calibration parameters are divided into two blocks.
First enter Block 1 parameters. Change parameter and acknowledge with [ENTER] to
go to next parameter. After last parameter of Block 1, program returns to the first, for
you to change.
Block 1 parameters:
•
Unit
•
Full Scale
•
Increment Value
•
No-Motion Difference
•
Zero Setting Range
•
Overrange
•
F-Mechanical
•
F-Calibration
•
L/C Rated Capacity
•
Load Cell Number
•
L/C-K [mV/V]
•
Deadload
•
Legal-For-Trade
Terminate calibration parameter input in Block 1 with [OK] key to acquire changes.
Brief display is output, e.g. ' 3000 Increments'. If you exit function with [ABORT] key,
changes are not acquired.
Operate [ENTER] key, and Block 2 calibration parameters are offered, for you to
change.
•
Scale ID
•
Class
•
Gravity Deviation
•
User-def. MIN load
®
