5.4.2.10 Parameter 'Load Cell Rated Capacity'

Display: RatedCp 1000kg
Input always 1 - 999999
in [kg]: Default = 1000
Function: Indicates rated capacity of load cells use
If a load cell is loaded with its rated capacity, it will output as measuring
sign al, at 1V supply voltage, the voltage corre
cha racteristic (Parameter Lo
Comments: Ent er always in kg. Rated cap
conve rted into kg.
5

.4.2.11 Parameter 'Number of Load Cells'

Display: No. of L/Cs 1
Input: Any value from 1 to 20
Default = 1
Enter value witho
Function: Indicates number of load cells used.
Pivots, if any, do not count.
5.4

.2.12 Parameter 'Load Cell Characteristic'

Display: L/C-C [mV/V] 2.85
Input: Any value from 0.1 to 10
Default = 2.85
Functio n: Load cell characteristic (rated ch
(measuring signal) a load cell supplies as a function of supply voltage, if
loaded with its rated capacity.

5.4.2.13 Parameter 'Dead Weight'

Display: Deadw. +
Input: Any value fro
Default = 0.00
Function: Dead weight means
acting on load cells in addition to effective load, i.e. the load to be weighed.
Dead weight is acquired during dead weight calibration and stored as
calibration parameter Dead Weight.
Besides the Calibration Factor, it is one of the two parameters that need not
be entered.
Merely in theoretical calibration, correct dead weight value has to be
entered in manual.
®
