Setting Mode

5.3.1 Fct. 42:FUNCTION VARIANT

5.3.1.1 Fct. 421:Parameters

The parameters to be changed depend on the function variant activated in item
'423:Load Variant'.
For parameters, see respective function variant in item 6.

5.3.1.2 Fct. 423:Load Variant

Use menu item to load a function variant (scale configuration) with pre-defined
parameters (see item 6).
After loading a variant, parameters should be adjusted by menu item
'421:Parameters'!

5.3.2 Fct. 43:PERIPHERALS

This item includes information on
•
Configuration of national settings (e.g. dialog language), serial interfaces (for
EDP, Disonet, printer, secondary display and fieldbus) and control station
•
Event classes
•
Analog output calibration.

5.3.2.1 Fct. 431:National Language Support

Use function to enter national settings on dialog language, character set, external
keyboard and decimal sign, one after the other.
After exit of function, changes are effective; further functions are used in the newly
selected environment.
Operating Sequence
After call of function, a number of scroll fields appears, for you to select the desired
settings:
Dialog Language:
431:National language support
Language English
On standard, DISOMAT comes with English dialog language. Further languages are
available and a second language can be loaded using the DISOPLAN software
(German is loaded ex works). Using this function, you can change over from first to
second language and vice versa, i.e. you can selected between English and Loaded
language.
Character Set:
431:National language support
Character set West European
Select between West European, East European and Cyrillic.
