Schenck process Disomat Opus Operating Manual page 119

Function Variants
Block 'Analog Source'
Source Gross
MIN reference value 0
MAX reference value 0
Block 'PLS-AOut'
Reference value 20
Block 'Analog Output'
Analog output OFF
®
DISOMAT Opus – Operating Manual
© Schenck Process GmbH, Darmstadt
This block selects what quantity is issued at the analog
output and how it is scaled.
Some quantities and reference values are:
Source
Gross:
Net:
dW/dt:
Fieldbus:
Controller magnitude: Not available in Opus;
Setpoint:
Actual value %:
Actual value of dim:
Residual value %:
Residual value of dim: The scale's dimension
Next setpoint
= MAX Scaling the parallel output of the analog output to the
reference value PLS analog output 1.
4 - 20 mA
Crane Scale
Dimension for Min/Max
The scale's dimension
The scale's dimension
The scale's dimension / h
none; the IEEE value of
the PLS-AIn is issued
output is set to 0
The scale's dimension
Percent of setpoint
The scale's dimension
Percent of setpoint
The scale's dimension
