Setting Mode
Parameter
Protocol
Determines the EDP protocol to be
used for communication.
Data Block (data block address)
Input is required only if a SIMATIC
S5 is connected. S5 enters data sent
from DISOMAT direct into data block.
Decimal Sign
Determines decimal sign used in
messages in case of floating points
numbers.
*) Please note: Interfacing via Modbus can alternatively be set using function
'4334:Fieldbus' (look there).
Operating Sequence
Start function and enter scale number:
4331:EDPScale number
Select one of eligible EDP interfaces:
4331:EDPEDP Interface Off
Select interface protocol:
4331:EDPProtocol 3964R
Enter data block information:
4331:EDPData Block
Select decimal sign for floating point numbers:
4331:EDPDecimal point (.)
Operate [OK] key and exit function. EDP interface is configured.

5.3.2.5 Fct. 4332:Printer

Use menu item to determine the physical assignment of printer interface to the
available interface outputs (S1 to S3) as well as the type of printer (local or remote).
NOTE: In addition, configure interface as such using menu item '432:Interfaces'.
ATTENTION: If interface assignment produces a conflict, system outputs an
event message.
®
DISOMAT Opus – Operating Manual
© Schenck Process GmbH, Darmstadt
Setting Using Configuration Password
Enter / Select
3964R (Siemens)
S5 (for Siemens SPS S5)
DDP8672 (e.g. for connection of a
legal-for-trade SCHENCK PC)
Mod-Bus *)
DDP8785
(MINPROZ)
Comma (,)
Point (.)
0
0
Default
3964R
0
Comma
(,)
