Function Variants

6.2 Filling Scale

6.2.1 General Functioning

Before operating a filling scale, make yourself familiar with the general
functioning of your DISOMAT.
The filling scale is designed to fill material from a surge hopper into a weigh hopper.
Single and multiple fill operations are possible.
Filling
DISOMAT controls a fill unit for filling in full feed and dribble feed until setpoint is
reached. the amount fed out is checked for tolerance; if required, make-up filling takes
place. In case of overfill, an event message is output.
To start filling,
•
Press F1 key, or
•
Set input contact 1, or
•
Send EDP command or
•
PLS contact.
To stop filling,
•
Press F2 key, or
•
Set input contact 2, or
•
Send EDP command or
•
PLS contact.
