Function Variants
Parameter Name Default Required
Setting
Source
Gross
M IN reference 0
value
MAX reference 0
value
Block 'PLS-AOut'
Reference value 20
Block 'Analog Output'
Analog output OFF

6.4 Crane Scale

6.4.1 General Functioning

Before operating a crane scale, make yourself familiar with the general
functioning of your DISOMAT.
Ground-controlled crane scale:
Start basic functions via control unit (pendant or remote control). Output information
on weight and system status on large-size display. Enter all further settings on
DISOMAT keyboard.
Information from ground-controlled crane scale is output on large-size display
DLZ 055/DLZ 111 (weight value, error information, status messages):
Scale tared = Net
Scale exact zero = -0-
Printing active = Yellow LED
®
DISOMAT Opus – Operating Manual
© Schenck Process GmbH, Darmstadt
Recommended Comments
Setting
Th is block selects what quantity is issued at the analog
output and how it is scaled.
Some quantities and reference values are:
Source
Gross:
Net:
d W/dt:
Fieldbus:
Controller magnitude: Not available in Opus; output is
Setpoint:
Actual value %:
Actual value of dim:
Residual value %:
Residual value of dim: The scale's dimension
Next setpoint
= MAX reference Scaling the parallel output of the analog output to PLS
value analog output 1.
4 - 20 mA
Crane Scale
Dimension for Min/Max
The scale's dimension
The scale's dimension
The scale's dimension / h
none; the IEEE value of the
PLS-AIn is issued
set to 0
The scale's dimension
Percent of setpoint
The scale's dimension
Percent of setpoint
The scale's dimension
0630 BV-H2313 GB
- 107 -
