Normal Mode

4.2.10 Fct. b:Display tare

This function displays stored TARE weight of scale for some seconds.
Operating Sequence
b:Display tare
Right after operation of [ENTER] key, current TARE weight is displayed for some
seconds.

4.2.11 Fct. c:Test display

This test is a visual inspection of the display where alphanumerical
characters are pushed over all points on the display to be able to
identify missing pixels.
We recommend making this test at least once a day as regular
control.
Operating sequence:
c:Test display
The test is made for a couple of seconds when you press the [ENTER] key. After this
is finished, the activated function variant is shown such as:
Scale Identifier Crane
Information can be stored per input encompassing as much as 40 characters,
although the display only shows the first 20 characters. The remaining characters can
be gradually overlaid in the display with the [RIGHT arrow] and [LEFT arrow] keys.
You can call up more information lines by pressing [ENTER] or [OK]:
Type Normal
Class Trade Scale
SMALL ZEUS 2006-07-03
Version DOp vww20700/002
Date 13.07.2006 16:25:00
Serial No. 12345678
Access code 12hgtPQV *)
The test ends after all lines have been called up.
*) Access Code for Internet Download
Schenck Process offers its customers the latest documents and software for download
via Internet. Files are stored in a protected area accessible after access code input.
This menu item lets you generate a valid access code (sample).
®
