Normal Mode
O perating Sequence
Function first displays curr
6:Display Balance
B alance: +1256.0
After renewed operation of [ENTER] key, display shows current number of dumps,
e.g.
6:Display Bala nce
Dumps: 7
You can use [OK] to get to the display of sums for materials 1 and 2.

4.2.6 Fct. 7:Select fixed tare

Use menu item to tare a stored value, i.e. you need not key in tare value but can
se lect from a list. List may comprise maximum 9 fixed tare values (Fix1 ... Fix9).
Selection of a fixed tare weight with 0.00 value has the same effect as 'Clear
Tare'.
For simple selection of fixed tare values, these require to be entered. This is
done in 'S etting Mode' (Parameter password) using the '48:Fixed Tare input'
function.
O perating Sequence
After call of function, scroll f
7:Select fixed ta
F ixed tare F ix1
Use DIRECTION KEYS to select other value, if y
[O K] key, the display goes back to net by (Net).
Example
You wish to acquire the weights of bulk solids (NET weight) stored in different hopper
types of 5 different weights. The weight of each hopper is always the same. You we
the filled hopper (GROSS weight) and select hopper weight
A dvantage: You need not enter hopper weight in manual.

4.2.7 Fct. 8:Manual tare

Use menu item to enter tare value in manual.
A dmissible input range: [ 0 ... full scale value]
O perating Sequence
Input field displays current value of tare memory:
8:Enter Manual Tare
Tare: +__0.00
E nter desired value and acknowledge with [ENTER].
®
DISOMAT Opus – Operating Manual
© Schenck Process GmbH, Darmstadt
ent balance total, e.g.
ield display always shows parameter 'Fix1'.
re
Functionality in Menu Tree
ou desire so. When you press the
using fixed tare value.
