Event Messages

7 Event Messages
The DISOMAT displays hints on operating sequence and scale information in
alternating mode, e.g.
Designed to inform you about important events, these hints require a certain reaction.
Simple cases are designed for information only, severe cases, e.g. critical faults in
operation, require to be remedied and acknowledged.
For you to be able to classify these hints, every event message is assigned to an
event class identified by a code letter.
Hints of the following event classes are displayed:
Event Class Code
Message M
Warning W
Alarm A
Fault S
*) Never ack
identified!
7.1 Event Messag
Event messages are construc
KNNT T[- ID ]:Text
K = Class (1 digit)
NN = Event number (2 digit
TT = Task numbe
-ID = Optional ID number
:Text = Event text
The first letter (K) is the code letter of the event class currently assigned to the eve
The next 2-digit number (NN) is the unambiguous code of the reported event
(=consecutive number of all event texts). Next, the 2-digit number (TT) of the task
having started the even
d esigned to specify the cause of the reported event. After the double point, the event
is output in text form.
®
DISOMAT Opus – Operating Manual
© Schenck Process GmbH, Darmstadt
A0209:Powerfail
Significance Required Reaction
Informative Note
Uncritical Acknowledge *)
Critical Acknowledge *)
Very critical Acknowledge after password input *)
nowledge event message before cause of fault has been
e Constr uction
ted as follows:
s)
r (2 digits)
t is output. Optionally, an ID number (ID) can be output

Event Message Construction

0630 BV-H2313 GB
nt.
