Schenck process Disomat Opus Operating Manual page 106

Function Variants
Parameter Name Default Required
Setting
Timeout 0.0
Discharge Time 0.0
Taring Yes Yes = Filling with
automatic taring
No = Filling without
automatic taring
Settling time: 0.0
Block 'Single Printout'
Timeout 0.0
Printing option OFF
Block 'Print Total'
Timeout 0.0
Printing option OFF
Block 'Print Balance''
Timeout 0.0
Printing option OFF
Block 'Analog Source'
Source Gross
MIN reference 0
value
MAX reference 0
value
BV-H2313 GB 0630
- 100 -
Recommended Comments
Setting
0 sec: Tare memory is not cleared after
feeding
> 0 sec: Tare memory cleared after input
time. Restart only possible after
this time.
Maximum discharge time; this time ends if it
goes below the discharge weight.
Time that can be set between the main
contact dropping (dribble feed) and
tolerance check
0 sec: Print-out without no-motion
1-999 sec: Waiting-time to no-motion
'OFF':
'to data
processing
system':
'Balance':
'data
processing
system/bal
ance':
see above
see above
This block selects what quantity is issued at
the analog output and how it is scaled.
Some quantities and reference values are:
Source
Gross:
Net:
dW/dt:
Fieldbus:
Controller
magnitude:
Setpoint:
Actual value %:
Actual value of
dim:
Residual value
%:
Residual value of
dim:
Next setpoint
®
DISOMAT Opus – Operating Manual
© Schenck Process GmbH, Darmstadt
Filling Scale
state monitoring
state.
No data output to the data
processing system and no
balancing
Data output to the data
processing system after printout
Balance before printout
Balance before printout and
output data to the data
processing system after printout
Dimension for Min/Max
The scale's dimension
The scale's dimension
The scale's dimension/h
none; the IEEE value of
the PLS-AIn is issued
Not available in Opus;
output is set to 0
The scale's dimension
Percent of setpoint
The scale's dimension
Percent of setpoint
The scale's dimension
The scale's dimension
