5.4.2.6 Parameter 'Zero Setting Range'

Display: ZeroingRange 4%
Selection: 0%; 2%; 4%; 10%; 20%;
Default = 4%
With certified scales: Max. 4%
Function: Together with parameter Full Scale Value, defines the range available
for zero setting.
Enter value in percent of full scale.
Comments: Weighing range is not restricted by zero setting.
Zeroing range is asymmetrical to zero point:
10% =
20% = -10.0 .... +10.0
If Parameter 'Legal-for-Trade' = Yes, only inputs to max. 4% are
admitted.

5.4.2.7 Parameter 'Overrange'

Display: Overrange 9d
Selection: 100%; 101%; 102%; 110%; 9d
Default = 9d
Enter value in % or d (digit). With certified scales: 9d
"d" refers to the number of digits, or smallest possible resolution of
weighing range. This value corresponds to the scale increment value.
Function: Relative to parameter Full Scale Value, defines what weight above full
scale value is displayed still. If weight of load exceeds overrange, symbol
"oooooo" is displayed provided that Parameter ' Legal-for-Trade' is set to
Yes. If 'Legal-for-Trade' is set to 'No', you will know the overrange by the T
symbol; the weight value continues being displayed.

5.4.2.8 Parameter 'Mechanical Factor'

Display: F-mech
Input: Any value from 0.1 to 99999
Default = 1,00
Enter value without unit.
Function: The mechanical factor considers the mechanical scale construction, e.g.
transmission, lever, and load application ratios.
F-mech = Load on scale / load on load cell
Comments: With scales with no load reduction or transmission ratio, factor is 1.0000.
Value < 1.0000: Load reduction ratio
Value > 1.0000: Load transmission ratio
®
