Setting Mode
Acknowledge calibration parameter input in Block 2 with [OK] key, and changes are
stored. Exit function with [ABORT] key, and changes get lost.
Function is terminated.

5.4.2.2 Parameter 'Unit'

Display: Unit kg
Selection: t - tons
kg - kilograms (= default)
g - grams
lb - pound
N - Newton
kN - Kilo-Newton
Function: Determines the weight unit in your DISOMAT. This holds for the input of all
parameters (e.g. pre-act contact, main contact) and for the weight display
(home position).

5.4.2.3 Parameter 'Full Scale Value'

Display: Max. Val. [selected unit]
Input: Any value from 0.1 to 9000000
Default = 600.000
Function: Defines full scale value. With multi-range or multi-divisional scales, value
refers to the big range.
Attention: Parameter Full Scale Value is directly related to parameter
Increment Value. Both values have to coincide.

5.4.2.4 Parameter 'Increment Value'

Display: Digit [selected unit] 0,200
Input: Any value from 0.001 to 1000
Default = 0.200
Function: Defines increment value and thus resolution of scale.
Comments: Increment value, together with parameter Full Scale Value, determines
the number of scale increments,
Increments = Full Scale Value/Increment Value
Possible are increments of 1; 2; 5.
If entered increment is not useful, event message 'W1211:Digit Wrong' is
output.

5.4.2.5 Parameter 'No-Motion Difference'

Display: Setting.Diff. 1d
Selection: 0d; 1d; 2d; 4d;
Default = 1d
Enter increment value.
Function: Together with parameter No-Motion Time, defines when scale is to
recognize no-motion.
No-motion is recognized if values measured during no-motion time do not
differ from values measured last by more than no-motion difference
allows.
Comments: Enter no-motion time at menu item '444:Scale Parameters'.
If Parameter 'Legal-for-Trade' = Yes, only input '1d' is admitted.
BV-H2313 GB 0630
- 76 -
Setting Using Calibration Password
600.000
