DISOMAT Overview
Control Block Key Functions
[RIGHT arrow]:
Home Position: Function key [F3] = <function according to function
Menu Tree:
[SHIFT] + [RIGHT arrow]:
Home Position: Function key [F6] = <function according to function
Menu Tree:
[ENTER]:
Home Position: n/a
Menu Tree:
[SHIFT] + [ENTER]:
Home Position:
Menu Tree:
[OK]:
Home Position:
Menu Tree:
BV-H2313 GB 0630
- 14 -
variant>
a) No function started: Move to the right on menu
tree level.
b) Function started: Scroll to the right in scroll
field. Shift cursor one position to the right in
input field.
variant>
a) No function started: n/a
b) Function started: Sets cursor to end of input
field; with longer input fields, blockwise (20 digits)
to the right.
a) No function started: Call up function selected
in menu tree.
b) Function started:
- Acquire input field inputs.
- Go to next input or scroll field if multiple inputs
are required.
- Go to next output field if function readies
various outputs
Acknowledge event messages.
a) No function started: Acknowledge event
messages.
b) Function started: Deletes the character left of
cursor in an input field; any text right of cursor is
shifted to the left ('BackSpace').
n/a
a) No function started: n/a
b) Function started: Close data input and acquire
if function calls for multiple inputs one after the
other.
