Setting Mode

5.4.2.14 Parameter 'Legal-For-Trade'

Display: L-f-T: Yes
Selection: Yes; No
Default = Yes
Function: The legal-for-trade status determines whether the scale is subject to official
verification or not. This affects various monitoring and display functions of
your scale.
The information below refers to Block 2.

5.4.2.15 Parameter 'Scale ID'

Display: ScaleID Scale 1 (e.g.)
Input: Any text, max. 7 digits
Function: Defines the name of your scale.

5.4.2.16 Parameter 'Class'

Display: Class Commercial Scale Cl. III
Selection: Commercial scale Class III, ordinary accuracy weighing machine; Cl.IIII,
self-acting filling scale; user-defined minimum load.
Function: Defines the scale accuracy class. Depending on application, minimum
load, etc. may change.

5.4.2.17 Parameter 'Gravity Deviation'

Display: G-deviation [per mil] + 0.000
Input: Deviation in per mil in accordance with formula:
Value = 1000 × (G-calibration site - G-mounting site) ÷
G-calibration site
Default = 0
Function: Described during verification in the manufacturer's works, this parameter
corrects the difference in gravitational force existing between verification
and mounting sites. Relevant are geographical latitude and sea level.
If verification takes place at the mounting site (normal case), parameter is
always zero.

5.4.2.18 Parameter 'User Def. MIN Load'

Display: User-def. MIN Load [current unit]
Input: Minimum load on scale in current unit
Default = 0
Function: This parameter determines the MIN value of the electronic stamping plate
provided that Parameter 'Class' has been set to 'User-def.MIN Load'.
