Setting Mode
Example
The 'Form1' sample shows how the change is effected.
'Form Format 1', e.g., creates the following printout
11.01.00 12:30
55,56kg Net
and consists of code: P1,D,P10,U,P18,LN,P27,BZ,P40,B,T,N,F1
Code elements are defined as under:
Code Meaning
P1 Go to column 1
D Output current date
P10 Go to column 10
U Output current time
P18 Go to column 18
LN Output consecutive number of weighing
P27 Go to column 27
BZ Output (entered) string
P40 Go to column 40
B Output Gross weight
T Output Tare weight
N Output Net weight
F1 1 * page feed
You wish to change format such that
•
additional text 'SCHENCK scale with DISOMAT' appears in first line left-flush
•
tare value is no longer output.
Printout is to look like thus:
SCHENCK scale with DISOMAT
<Blank>
11.01.00 12:30
Relevant code is constructed as follows (changes are boldface printed):
SCHENCK scale, with DISOMAT,Y2,P1,D,U,LN,P27,BZ,P40,B,N,F1
®
DISOMAT Opus – Operating Manual
© Schenck Process GmbH, Darmstadt
1234 DA-RC 30
1234 DA-RC 30
Setting Using Parameter Password
123,45kg G 67,89kg
Example
11.01.00
12:30
1234
DA-RC 30
123.45kg G
67.89kg T
55.56kg Net
123.45kg G 55.56kg Net
0630 BV-H2313 GB
T
