Setting Mode

5.5 Fct. 5b:Reset All(Restart)

Restart is required, for instance, if recommended by event messages of Class 'S'
(Fault).
ATTENTION: Perform restart right before completing commissioning. After restart of
DISOMAT , ONLY event message "A03XX Restart" may be available. Any other event,
particularly parameter errors, must be remedied before commissioning can be br
to complet ion.
Restart ('Reset all') loads all parameters from EEPROM memory into main
memory (RAM). In EEPROM, data (parameter values, function block
linkages) are
All data in main memory are overwritten.
Operating Seq uence
Before restarti ng system, enter Restart password (see Item 5.1). After successful
in put, another menu item appears in SERVICE menu:
5b:SERVICE
Reset All
Start with [ENTER] key, and system prompts:
5b:Reset All
Acknowledge Yes
Acknowledge with [ENTER] key, or enter 'No'.
If you select 'Yes', the hint
5b:Reset All
Restart
is displayed for some seconds before DISOMAT outputs A0309-99:Restart and
returns to home position.
Acknowledge with [ACK] key, and DISOMAT is again ready to operate.
BV-H2313 GB 0630
- 92 -
stored fail-safe.
Fct. 5b:Reset All(Restart)
®
DISOMAT Opus – Operating Manual
