Function Variants

6.6.4 Function Keys

With the ZEUS road/rail weigh bridge configuration, function keys are assigned as
follows
'First Weighing'
F1 key: 'First Weighing'
'Second Weighing'
F2 key: 'Second Weighing'
'Perform Weighing Operation'
F3 key: 'Single Weighing'
'Repeat Printing of Weighing Report'
F4 key: 'PrintRepeat'
'Record Weight Without Veh
F5 key: 'External Weighing'
Used, e.g. to check vehicle for overload.
'Switch Exit Signal to GREEN without weighing'
F6 key: 'Exit Free'

6.6.5 Inputs and Outputs

Inputs
Phys.
In 1:
In 2:
In 3:
In 4:
Output
Phys.
Out 1:
Out 2:
Out 3:
Out 4:
AnalogOut
BV-H2313 GB 0630
- 120 -
:
Signal Function:
PLS-DIn1 n/a
PLS-DIn2 n/a
PLS-DIn3 n/a
PLS-DIn4 n/a
s:
Signal Function:
PLS-DOut1 Exit signal, RED light
PLS-DOut2 Exit signal, GREEN light
PLS-DOut3 Entrance signal, RED light
PLS-DOut4 Entrance signal, GREE
n/a Dep
Weighbridge ZEUS
icle Empty Weight'
N light
ending on choice
®
