Event Messages
Display Text
W4204-1:Setpoint
W4204-2:Setpoint
W4304:Fill value too low
W4404:Excess feeding
W4404-1:Excess feeding
W4504:Out of Tolerance
W4504-1:Out of Tolerance
W4504-2:Out of Tolerance
W4504-10:Out of Tolerance
W4604-1:Weight invalid
W4604-2:Weight invalid
W4605:Weight invalid
W4606:Weight invalid
W4606-1:Weight invalid
A4804:Analog cable broken
A5004-10:Function block linkage
A5004-11:Function block linkage
A5004-nnn:Function block linkage **)
A5104:Analog output wrong calibr.
M5204-1:Function not accessible
M5204-2:Function not accessible
M5204-3:Function not accessible
M5304-1:Weighing aborted
M5304-2:Weighing aborted
M5304-3:Weighing aborted
W5404:Empty check
W5504:Contact check
W5604:Scale not permitted
W5604-1:Scale not permitted
W6020:PLS doesn't send
A6519-n:ICP Communication Error
W7002-1:EDP Error
W7003-1:EDP Error
W7003-2:EDP Error
W7003-3:EDP Error
W7003-5:EDP Error
BV-H2313 GB 0630
- 138 -
List of Event Messages
Edit *) Cause
* Too low
* Too big
*
* Setpoint causes overfill.
* Setpoint exceeds maximum fill
value.
* Out of POSITIVE tolerance
* Refilling exceeds setpoint.
* SWA: below MINUS tolerance,
refilling cut off
* SWA: entered tolerance
excessive
* INVALID upon printout
* OVERFLOW upon printout
* Upon printout INITIALISATION
or INVALID
* ZEUS fixed tare weighing
* ZEUS fixed tare weighing (Net
< 0)
*
Wrong input linkage.
In fixed wiring
1:Unknown function block
2:Wrong input number
3:Unknown output
* First weighing
* Second weighing
* Single weighing
* ZEUS first weighing: Weight
cannot be used.
* ZEUS second weighing: Weight
cannot be used.
* ZEUS single weighing: Weight
cannot be used.
Bin tare out of configured limits Empty bin.
Filling spout misses bung hole
SWA: selected scale not
admitted for feeding
FILLING/DISCHARGE scale:
seleted scale not admitted
External fieldbus master stops
polling controller
With ICP module to address n
* Internal status processing
* Internal timer
* Establishing connection to
interface task
* Message sending error
* Order timeout elapsed
®
