Function Variants

6.4.5 Parameters

Table of parameters for the 'Crane Scale Function Variant'
Parameter Name Default Required
Block 'Single Printout'
Timeout 0.0
Printing option OFF
Block 'Print Total'
Timeout 0.0
Printing option OFF
Block 'Print Balance'
Timeout 0.0
Printing option OFF
Block 'Slack Rope'
FastComp.High
FastComp.Low
Block 'Overload'
FastComp.High
FastComp.Low
Block 'Double-Print Lock'
Type Percent
ON 4%
OFF 5%
Block 'High Lifting Speed'
Type Percent
ON 110%
OFF 109%
BV-H2313 GB 0630
- 112 -
Recommended
Setting Setting
HIGH >
LOW
LOW >
HIGH
If changeover
is required,
enter
corresponding
values.
Comments
0 sec: Print-out without no-motion state
monitoring
1-999 sec: Timeout to no-motion state
'OFF': No data output to the data
processing system and no
balancing
'to data Data output to the data
processing processing system after
system': print-out
'Balance': Balance before print-out
'data processing Balance before print-out
system/balance': and data output to the data
processing system after
print-out
see above
see above
Slack rope detection.
Contact drops if weight falls below set OFF value.
The difference between ON/OFF produces hysteresis.
Overload protection device;
Contact drops if weight exceeds set OFF value.
The difference between ON/OFF produces hysteresis.
The "Crane Relieved" criterion is used to avoid
unintended double printout with double balancing.
Changeover load to be lifted; practically cut-off by
default setting.
®
