Setting Mode
Data:
432:Interfaces
Data: 8-bitno__
To determine number of data bits and type of parity check, there are the following
possibilities:
8-bit no Data bits: 8; parity: No
8-bit even Data bits: 8; parity: Even
7-bit even Data bits: 7; parity: Even
8-bit odd Data bits: 8; parity: Odd
7-bit odd Data bits: 7; parity: Odd
Stop Bits:
432:Interfaces
Stop bits: 1
Select '1' or '2'.
Acknowledge with [OK] key to exit function. Selected interface is configured.

5.3.2.3 Fct. 433:COMMUNICATION

This menu offers the functions for setting communication with external devices.

5.3.2.4 Fct. 4331:EDP

Use menu item to physically assign the EDP interface to one of the existing interface
outputs (S1 to S3).
NOTE: In addition, configure interface using menu item '432:Interfaces'.
If interface assignment produces a conflict with printer or secondary display,
system outputs an event message, e.g. 'M3406:Interface already open'. In
this event, the peripheral instruments have to be assigned differently to the
interfaces.
Before using function, set the following parameters:
Parameter
Scale Number
Determines DISOMAT logical
address; must always be included in
message header (also if DISOMAT
operates out of network).
EDP Interface
Physically assigns EDP interface to
available interface outputs (S1 to
S3). If no EDP system is connected,
select 'Off'.
BV-H2313 GB 0630
- 64 -
Setting Using Configuration Password
Enter / Select
0 ... 255:
0 ... 99 with SCHENCK Standard
Protocol (DDP8672) and 3964R
Protocol;
0 ... 255 with S5/Teleperm M and J-
Bus
Off, S1, S2, S3
®
DISOMAT
© Schenck Process GmbH, Darmstadt
Default
0
Off
