6.4.3 Inputs and Outputs

Inputs:
Phys. Signal
In 1: PLS-DIn1
In 2:
In 3: PLS-DIn3
In 4: PLS-DIn4
n/a PLS-DIn2
n/a PLS-DIn5
Outputs:
Phys. Signal
Out 1: PLS-DOut1 Slagging rope
Out 2: PLS-DOut2 Overload
Out 3: PLS-DOut3 Switching the elevated load to higher performance
Out 4: PLS-DOut4 Ready to operate (no fault)
AnalogOut
The PLS-DIn or PLS-DOut signals are used to control the scale by computer or
fieldbus. They function at the same time as the physical inputs or outputs.
Exceptions: PLS-DIn2 Quit event message
PLS-DIn5 Set to zero / Test
BV-H2313 GB 0630
- 110 -
Function:
Set Tare / Clear Tare
n/a Set to zero / Test (short)
Quit Event message (long)
Print total and clear balance
Weigh and print
Quit event message
Set to zero / Test
Function:
n/a Depending on choice
®
