Event Messages
Display Text
S1412-2:Foreign Dongle
M1511-1:Communication Error
M1512-1:Communication Error
M1511-2:Communication Error
M1512-2:Communication Error
M1511-3:Communication Error
M1512-3:Communication Error
M1511-4:Communication Error
M1512-4:Communication Error
M1511-5:Communication Error
M1512-5:Communication Error
M1511-6:Communication Error
M1512-6:Communication Error
M1511-7:Communication Error
M1512-7:Communication Error
M1511-9:Communication Error
M1512-9:Communication Error
M1520-1:Communication Error
M1520-2:Communication Error
W1611:Write Error
W1612:Write Error
W1711-1:Write Error
W1712-1:Write Error
W1711-2:Write Error
W1712-2:Write Error
W1711-3:Write Error
W1712-3:Write Error
W1711-4:Write Error
BV-H2313 GB 0630
- 136 -
List of Event Messages
Edit *) Cause
Check number measurement
showed that the serial number
stored in dongle is incorrect.
Read error in communication
with Measuring Module 1
Read error in communication
with Measuring Module 2
Write error in communication
with Measuring Module 1
Write error in communication
with Measuring Module 2
Scale 1 measuring rate not
converted
Scale 2 measuring rate not
converted
Scale 1 switching filter time not
converted
Scale 2 switching filter time not
converted
Scale 1 display filter time not
converted
Scale 2 display filter time not
converted
Scale 1 default check number
not determined
Scale 2 default check number
not determined
Scale 1 sensitivity not
determined
Scale 2 sensitivity not
determined
Scale 1 filter data not active
Scale 2 filter data not active
Fieldbus: unknown Write ID
Fieldbus: inknown Read ID
Write operation into dongle or
measuring module 1
incomplete
Write operation into dongle or
measuring module 2
incomplete
Write operation into dongle 1
incomplete
Write operation into dongle 2
incomplete
Write operation into dongle 1
faulty
Write operation into dongle 2
faulty
Write operation into dongle 1
faulty
Write operation into dongle 2
faulty
Write operation into dongle 1
faulty
®
DISOMAT Opus – Operating Manual
© Schenck Process GmbH, Darmstadt
Remedy
Re-acquire
calibration
parameters Part
2.
Re-acquire
calibration
parameters Part
2.
Re-acquire Scale
1 parameters.
Re-acquire Scale
2 parameters.
Re-acquire Scale
1 parameters.
Re-acquire Scale
2 parameters.
Recall diagnosis.
Recall diagnosis.
Recall diagnosis.
Recall diagnosis.
Re-acquire data.
Re-acquire data.
Check settings.
Check settings.
Re-plug dongle.
Re-plug dongle.
Repeat last
editing.
Repeat last
editing.
Dongle code 1
cannot be
written.
Dongle code 2
cannot be
written.
Dongle 1: write
access
incomplete
