Setting Mode

5.4.3 Fct. 442:Special Scales

DISOMAT knows three operating modes:
•
Normal scale (Single-range scale)
•
Multi-divisional scale (2 or 3 ranges)
•
Multi-range scale (2 or 3 ranges).
Unlike the normal scale, the multi-divisional or multi-range scale has multiple weighing
ranges (with 2 ranges: small and big range; with 3 ranges: small, medium and big
range).
Calibration and scale parameters are identical for all ranges, except Full Scale Value
and Increment Value.
Enter big range parameters in the exact same ways as the single-range scale
parameters; small range parameters, at menu item '442:Mode'.
With two ranges, range and increment value can be set for the medium
range; however, this is of no influence.
Parameters
Small range parameters to be set:
•
Scale type
•
Small range full scale value
•
Small range increment value
•
Medium range full scale value
•
Medium range increment value.
Parameter input for multi-divisional/multi-range scales is identical.
Display and Printout
The currently active range is highlighted in the upper display line.
Ex.: Max. 80 / 200 kg
i.e. 80 highlighted means that small range, here: 80
kg, is active.
Change-over of range has no effect on display and printout. Display always shows the
after-comma places of the small range. When defining ranges and increment value,
have in mind that maximum 6 places plus comma (e.g. 1000.00) are available in the
display.
Operating Sequence
Use DIRECTION KEYS to go to menu item
442:SCALE
Special scales
and acknowledge with [ENTER] key.
Change parameter and acknowledge with [ENTER] to go to next parameter. After last
parameter of Block 1, program returns to the first, for you to change.
Acknowledge calibration parameter input with [OK] key, and changes are stored. Exit
function with [ABORT] key, and changes get lost.
The operation is complete.
®
