Normal Mode

4.2.4.5 Fct. 55:Select Home Position

This function is used for selecting system information that appears alternately with the
weight display in the display in the 'basic position' operating state.
Refer to the 'Basic Position Display' for possible displays.
The current selection appears after calling up the function, such as
1 : Date/Time
You can change the selection with the DIRECTION KEYS.

4.2.4.6 Fct. 58:Set higher range

This function switches a multi-range scale into the next-higher range.
This is necessary when a road weigh bridge does not come to a standstill in
the small range due to wind.

4.2.5 Fct. 6:Display balance

Use menu item to display balance total.
NOTE: This display corresponds to the total of all 2 materials counters (see also
Format Variable 'BI'). You can access single materials balances using format variables
'BI1' to 'BI10'. Next display after balance total shows individual material totals.
When Does Summation Take Place?
•
With Filling/Receiving Scale, balancing takes place automatically after every
filling/discharge operation.
•
With all other scales, summation takes place upon printing (depending on
configuration).
What Is Summated?
Every operation increments the number of dumps by 1, and balance total by the
acquired weight value.
Operations are filling processes, aborted or completed, and all printing operations
started via keyboard or contact input.
No balancing takes place if printout is started using menu items '31:Print 1', '32:Print
2', '33:Print 3', '36:Print 4', '37:Print 5', '38:Print 6' and '35:Print Repeat'.
What Is Displayed?
You can display current balance total and current number of dumps.
Example
30 kg each time are filled. After 9 filling operations, balance total is 270 kg. Maximum
balance total is 280 kg.
You can enter balance total and maximum number of dumps at menu item '471:Max.
Balance/Dumps' after input of parameter password.
