Tektronix Keithley 2651A Reference Manual page 871

Section 13: LAN concepts and settings
Setting the gateway
Contact your corporate information technology (IT) department to secure a valid gateway for the
instrument when placing the instrument on a corporate network.
To set the gateway when LAN configuration method is set to MANUAL:
1. From the front panel, press the MENU key, and then select LAN > CONFIG > GATEWAY.
2. Turn the navigation wheel to select and enter a valid gateway address for the instrument.
3. Press the ENTER key to confirm the changes.
4. Press the EXIT (LOCAL) key once to return to the LAN CONFIG menu.
5. Select APPLY_SETTINGS > YES, and then press the ENTER key.
Setting the subnet mask
Contact your corporate information technology (IT) department to secure a valid subnet mask for the
instrument when placing the instrument on a corporate network.
To set the subnet mask when LAN configuration method is set to MANUAL:
1. From the front panel, press the MENU key, and then select LAN > CONFIG > SUBNETMASK.
2. Turn the navigation wheel to select and enter a valid subnet mask for the instrument.
3. Press the ENTER key to confirm the changes.
4. Press the EXIT (LOCAL) key once to return to the LAN CONFIG menu.
5. Select APPLY_SETTINGS > YES, and then press the ENTER key.
Configuring the domain name system (DNS)
The Domain Name System (DNS) lets you type a domain name in the address bar to connect to the
instrument. If you use DNS, you can use a name instead of an IP address.
Example:
Model2651A.XYZcompany.com
Contact your corporate information technology (IT) department for information about DNS. If a DNS
server is not part of the LAN infrastructure, do not use this setting.
13-8
Model 2651A High Power System SourceMeter® Instrument Reference Manual
2651A-901-01 Rev. C October 2021
