Model 2651A High Power System SourceMeter® Instrument Reference Manual
smuX.trigger.autoclear
This attribute turns automatic clearing of the event detectors on or off.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
autoClear = smuX.trigger.autoclear
smuX.trigger.autoclear = autoClear
autoClear
Details
This attribute enables or disables automatic clearing of the trigger model state machine event
detectors when the SMU transitions from the arm layer to the trigger layer.
Only the detected states of the event detectors are cleared.
The overrun statuses of the event detectors are not automatically cleared when the SMU transitions
from the arm layer to the trigger layer.
The event detectors are always cleared when a sweep is initiated.
Example
smua.trigger.autoclear = smua.ENABLE
Automatically clear the event detectors for the trigger mode state.
Also see
Triggering (on page 3-36)
smuX.trigger.count
This attribute sets the trigger count in the trigger model.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
triggerCount = smuX.trigger.count
smuX.trigger.count = triggerCount
triggerCount
Details
2651A-901-01 Rev. C October 2021
Affected by Where saved
SMU reset Not saved
Instrument reset
Recall setup
Auto clear setting; set to one of the following values:
▪
0 or smuX.DISABLE: Turns off automatic clearing of the event detectors
▪
1 or smuX.ENABLE: Turns on automatic clearing of the event detectors
Affected by Where saved
SMU reset Not saved
Instrument reset
Recall setup
The trigger count is the number of times the source-measure unit (SMU) iterates in
the trigger layer for any given sweep
Section 7: TSP command reference
Default value
0 (smuX.DISABLE)
Default value
1
7-287
