Section 7: TSP command reference
ConfigPulseIMeasureV()
This KIPulse factory script function configures a current pulse train with a voltage measurement at each point.
Type TSP-Link accessible
Function No
Usage
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag,
sync_in, sync_out, sync_in_timeout, sync_in_abort)
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag,
sync_in, sync_out, sync_in_timeout)
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag,
sync_in, sync_out)
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag,
sync_in)
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag)
f
msg
smu
bias
level
limit
ton
toff
points
buffer
tag
sync_in
sync_out
sync_in_timeout
sync_in_abort
Details
Data for pulsed voltage measurements are stored in the reading buffer specified by the buffer input
parameter.
This function configures a current pulse train with a voltage measurement at each point.
Measurements are made at the end of the ton time.
7-38
Model 2651A High Power System SourceMeter® Instrument Reference Manual
Affected by Where saved
A Boolean flag; this flag is true when the pulse was successfully configured,
false when errors were encountered
A string message; if the f flag is false, msg contains an error message; if it is
true, msg contains a string that indicates successful configuration
Instrument channel (set to smua)
Bias level in amperes
Pulse level in amperes
Voltage limit (for example, compliance) in volts
Pulse on time in seconds
Pulse off time in seconds
Number of pulse-measure cycles
Reading buffer where pulsed measurements are stored; if this is nil when the
function is called, no measurements are made when the pulse train is initiated
Numeric identifier to be assigned to the defined pulse train
Defines a digital I/O trigger input line; if programmed, the pulse train waits for a
trigger input before executing each pulse
Defines a digital I/O trigger output line; if programmed, the pulse train generates a
trigger output immediately before the start of ton
Specifies the length of time (in seconds) to wait for input trigger; default value is 10 s
Specifies whether or not to abort the pulse if an input trigger is not received; if pulse
aborts because of a missed trigger, a timer timeout message is returned; true or
false
Default value
