Tektronix Keithley 2651A Reference Manual page 566

Model 2651A High Power System SourceMeter® Instrument Reference Manual
setup.recall()
This function recalls settings from a saved setup.
Type TSP-Link accessible
Function Yes
Usage
setup.recall(id)
id
Details
When the id parameter is an integer (n), it is interpreted as the setup number to restore from the
instrument's nonvolatile memory. When n = 0, the instrument recalls the factory default setup; when
n = 1 to 5, the instrument recalls a user-saved setup.
When the id parameter is a string, it is interpreted as the path and file name of the setup to restore
from a file on a USB flash drive. The path may be absolute or relative to the current working directory.
Before a setup is recalled, an instrument reset is performed.
Example 1
setup.recall(1)
Example 2
setup.recall("/usb1/KEITHLEY_30730.set")
Also see
Saved setups
setup.save() (on page 7-222)
2651A-901-01 Rev. C October 2021
Affected by
An integer or string that specifies the location of the setup to recall:
▪
Factory default setup: 0
▪
User-saved setup in nonvolatile memory: 1 to 5 User-saved setup on a USB
flash drive: "/path/filename"
(on page 2-42)
Section 7: TSP command reference
Where saved Default value
Recall the user-saved setup at location 1.
Recall a user-saved setup stored in a file
named KEITHLEY_30730 on a USB
flash drive.
7-221
