Model 2651A High Power System SourceMeter® Instrument Reference Manual
Example
status.operation.measuring.enable =
status.operation.measuring.SMUA
Also see
Operation Status Registers
status.operation.*
status.operation.remote.*
This attribute contains the operation status remote summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
operationRegister = status.operation.remote.condition
operationRegister = status.operation.remote.enable
operationRegister = status.operation.remote.event
operationRegister = status.operation.remote.ntr
operationRegister = status.operation.remote.ptr
status.operation.remote.enable = operationRegister
status.operation.remote.ntr = operationRegister
status.operation.remote.ptr = operationRegister
operationRegister
Details
These attributes are used to read or write to the operation status remote summary registers. Reading
a status register returns a value. The binary equivalent of the returned value indicates which register
bits are set. The least significant bit of the binary number is bit B0, and the most significant bit is bit
B15.
2651A-901-01 Rev. C October 2021
(on page 15-9)
(on page 7-329)
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
The status of the operation status remote summary register; a
zero (0) indicates no bits set (also send 0 to clear all bits); other
values indicate various bit settings
Section 7: TSP command reference
Uses a constant to set the SMUA bit
of the operation status measuring
summary enable register.
Where saved Default value
- - - -
Not saved Not applicable
Not saved 0
Not saved 0
Not saved 0
Not saved 2050 (All bits set)
7-359
