Model 2651A High Power System SourceMeter® Instrument Reference Manual
status.operation.sweeping.*
This attribute contains the operation status sweeping summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
operationRegister = status.operation.sweeping.condition
operationRegister = status.operation.sweeping.enable
operationRegister = status.operation.sweeping.event
operationRegister = status.operation.sweeping.ntr
operationRegister = status.operation.sweeping.ptr
status.operation.sweeping.enable = operationRegister
status.operation.sweeping.ntr = operationRegister
status.operation.sweeping.ptr = operationRegister
operationRegister
Details
These attributes are used to read or write to the operation status sweeping summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 15-1) and
this register are defined in the following table.
Bit Value
B0 Not used
status.operation.sweeping.SMUA
B1
B2-B5 Not used
In addition to the above constant, operationRegister can be set to the decimal equivalent of the
bit to set.
2651A-901-01 Rev. C October 2021
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
The status of the operation status sweeping summary register; a zero (0)
indicates no bits set (also send 0 to clear all bits); the only valid value other than
zero (0) is 2
Enable and transition registers
Section 7: TSP command reference
Default value
- -
Not applicable
0
0
0
2 (All bits set)
Status register set
(on page 15-19). The individual bits of
Description
Not applicable.
Set bit indicates that SMU A is sweeping.
Bit B1 decimal value: 2
Binary value: 0000 0010
Not applicable.
7-361
