Model 2651A High Power System SourceMeter® Instrument Reference Manual
Example 2
-- 18432 = binary 0100 1000 0000 0000
operationRegister = 18432
status.operation.enable = operationRegister
Uses the decimal value to set bits B11 and B14 of the operation status user enable register.
Also see
Operation Status Registers
status.operation.*
status.questionable.*
These attributes manage the questionable status register set of the status model.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
questionableRegister = status.questionable.condition
questionableRegister = status.questionable.enable
questionableRegister = status.questionable.event
questionableRegister = status.questionable.ntr
questionableRegister = status.questionable.ptr
status.questionable.enable = questionableRegister
status.questionable.ntr = questionableRegister
status.questionable.ptr = questionableRegister
questionableRegister
Details
These attributes are used to read or write to the questionable status registers. Reading a status
register returns a value. In the binary equivalent, the least significant bit is bit B0, and the most
significant bit is bit B15. For example, if a value of 1.22880e+04 (which is 12,288) is read as the value
of the condition register, the binary equivalent is 0011 0000 0000 0000. This value indicates that bits
B12 and B13 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
2651A-901-01 Rev. C October 2021
(on page 15-9)
(on page 7-329)
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
B13 B12 B11 B10
> > > >
1 1 0 0
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
The status of the questionable status register; a zero (0) indicates
no bits set (also send 0 to clear all bits); other values indicate
various bit settings
B9 B8 B7 B6 B5
> > > >
0 0 0 0
Section 7: TSP command reference
Default value
- -
Not applicable
0
0
0
13,056 (All bits set)
B4 B3 B2 B1
> > > > >
0 0 0 0 0
B0
*
0
7-367
