Model 2651A High Power System SourceMeter® Instrument Reference Manual
smua.trigger.measure.stimulus
This attribute selects the event that causes the measure event detector to enter the detected state.
Type
TSP-Link accessible
Attribute (RW)
Yes
Usage
eventID = smuX.trigger.measure.stimulus
smuX.trigger.measure.stimulus = eventID
eventID
Details
Set this attribute to the event ID of any trigger event generator to wait for that event. When set, the
SMU waits for the event at the measurement event detector portion of the trigger model.
Set this attribute to zero to bypass waiting for an event (the SMU continues uninterrupted through the
remote trigger model). Set eventID to one of the existing trigger event IDs shown in the
following table.
Trigger event IDs*
Event ID
smuX.trigger.SWEEPING_EVENT_ID
smuX.trigger.ARMED_EVENT_ID
smuX.trigger.SOURCE_COMPLETE_EVENT_ID
smuX.trigger.MEASURE_COMPLETE_EVENT_ID
smuX.trigger.PULSE_COMPLETE_EVENT_ID
smuX.trigger.SWEEP_COMPLETE_EVENT_ID
smuX.trigger.IDLE_EVENT_ID
digio.trigger[N].EVENT_ID
tsplink.trigger[N].EVENT_ID
lan.trigger[N].EVENT_ID
display.trigger.EVENT_ID
trigger.EVENT_ID
trigger.blender[N].EVENT_ID
trigger.timer[N].EVENT_ID
2651A-901-01 Rev. C October 2021
Affected by
Where saved
SMU reset
Not saved
Instrument reset
Recall setup
Event that triggers the measurement detector
Section 7: TSP command reference
Default value
0
Event description
Occurs when the source-measure unit (SMU) transitions
from the idle state to the arm layer of the trigger model
Occurs when the SMU moves from the arm layer to the
trigger layer of the trigger model
Occurs when the SMU completes a source action
Occurs when the SMU completes a measurement action
Occurs when the SMU completes a pulse
Occurs when the SMU completes a sweep
Occurs when the SMU returns to the idle state
Occurs when an edge is detected on a digital I/O line
Occurs when an edge is detected on a TSP-Link line
Occurs when the appropriate LXI trigger packet is
received on LAN trigger object N
Occurs when the TRIG key on the front panel is pressed
Occurs when a *TRG command is received on the
remote interface
GPIB only: Occurs when a GET bus command is
received
VXI-11 only: Occurs with the VXI-11 command
device_trigger; reference the VXI-11 standard for
additional details on the device trigger operation
Occurs after a collection of events is detected
Occurs when a delay expires
7-297
