Model 2651A High Power System SourceMeter® Instrument Reference Manual
Calibration commands quick reference
The following table summarizes remote calibration commands. For a more complete description of
these commands, refer to the
Calibration commands
Command
smua.cal.adjustdate = adjustDate
smua.cal.date = calDate
smua.cal.due = calDue
smua.cal.fastadc()
smua.cal.lock()
smua.cal.password = "newPassword"
smua.cal.polarity = calPolarity
smua.cal.restore(calset)
smua.cal.save()
calstate = smua.cal.state
smua.cal.unlock("password")
smua.measure.calibratei(range,
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
smua.measure.calibratev(range,
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
smua.source.calibratei(range,
cp1Expected, cp1Reference,
cp2Expected, cp2Reference)
2651A-901-01 Rev. C October 2021
TSP command reference
Description
Set date when the adjustment was done.
Set calibration date (calDate of 0 indicates date not set).
Set date when calibration should be performed (calDue of 0
indicates date not set).
Performs calibration adjustment of the fast analog-to-digital
converter (ADC).
Lock out calibration.
Change password to "newPassword".
Set polarity:
smua.CAL_AUTO (automatic polarity).
smua.CAL_NEGATIVE (negative polarity).
smua.CAL_POSITIVE (positive polarity).
Load set of calibration constants:
smua.CALSET_NOMINAL (nominal constants).
smua.CALSET_FACTORY (factory constants).
smua.CALSET_DEFAULT (normal constants).
smua.CALSET_PREVIOUS (previous constants).
Store constants in nonvolatile memory as DEFAULT
calibration set.
Request calibration state:
smua.CALSTATE_CALIBRATING
smua.CALSTATE_LOCKED
smua.CALSTATE_UNLOCKED
Unlock calibration (default password: KI0026XX)
Adjust current measurement range calibration*:
±range (measurement range to adjust).
cp1Measured (Model 2651A measured value for cal. point 1).
cp1Reference (reference measurement for cal. point 1).
cp2Measured (Model 2651A measured value for cal. point 2).
cp2Reference (reference measurement for cal. point 2).
Adjust voltage measure range calibration*:
±range (measurement range to adjust).
cp1Measured (Model 2651A measured value for cal. point 1).
cp1Reference (reference measurement for cal. point 1).
cp2Measured (Model 2651A measured value for cal. point 2).
cp2Reference (reference measurement for cal. point 2).
Adjust current source range calibration*:
±range (source range to adjust).
cp1Expected (source value programmed for cal. point 1).
cp1Reference (reference measurement for cal. point 1).
cp2Expected (source value programmed for cal. point 2).
cp2Reference (reference measurement for cal. point 2).
(on page 7-1).
Section 12: Calibration
12-21
