Example 1
standardRegister = status.standard.OPC + status.standard.EXE
status.standard.enable = standardRegister
Uses constants to set the OPC and EXE bits of the standard event status enable register.
Example 2
-- decimal 17 = binary 0001 0001
standardRegister = 17
status.standard.enable = standardRegister
Uses the decimal value to set the OPC and EXE bits of the standard event status enable register.
Also see
Standard Event Register
status.system.*
These attributes manage the TSP-Link
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
enableRegister = status.system.condition
enableRegister = status.system.enable
enableRegister = status.system.event
enableRegister = status.system.ntr
enableRegister = status.system.ptr
status.system.enable = enableRegister
status.system.ntr = enableRegister
status.system.ptr = enableRegister
enableRegister
Details
In an expanded system (TSP-Link), these attributes are used to read or write to the system summary
registers. They are set using a constant or a numeric value but are returned as a numeric value. The
binary equivalent of the value indicates which register bits are set. In the binary equivalent, the least
significant bit is bit B0, and the most significant bit is bit B15. For example, if a value of
1.29000e+02 (which is 129) is read as the value of the condition register, the binary equivalent is
0000 0000 1000 0001. This value indicates that bit B0 and bit B7 are set.
2651A-901-01 Rev. C October 2021
(on page 15-21)
®
system summary register of the status model for nodes 1 through 14.
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
The status of the system summary register; a zero (0) indicates no bits set; other
values indicate various bit settings
Section 7: TSP command reference
Default value
- -
Not applicable
0
0
0
32,767 (All bits set)
7-383
