Model 2651A High Power System SourceMeter® Instrument Reference Manual
smuX.trigger.SWEEP_COMPLETE_EVENT_ID
This constant contains the sweep complete event number.
Type TSP-Link accessible
Constant Yes
Usage
eventID = smuX.trigger.SWEEP_COMPLETE_EVENT_ID
eventID
Details
Set the stimulus of any trigger object to the value of this constant to have the trigger object respond to
sweep complete events from this SMU.
Example
digio.trigger[2].mode = digio.TRIG_RISINGA
digio.trigger[2].clear()
smua.trigger.source.stimulus = digio.trigger[2].EVENT_ID
digio.trigger[4].mode = digio.TRIG_RISINGM
digio.trigger[4].pulsewidth = 0.001
digio.trigger[4].stimulus = smua.trigger.SWEEP_COMPLETE_EVENT_ID
Configure the Model 2651A to detect a rising edge on digital I/O line 2.
Configure SMU A to start its source action when a trigger event occurs on digital I/O line 2.
Configure digital I/O line 4 to output a 1 ms rising-edge trigger pulse at the completion of the SMU sweep.
Also see
Triggering (on page 3-36)
smua.trigger.SWEEPING_EVENT_ID
This constant contains the sweeping event number.
Type TSP-Link accessible
Constant Yes
Usage
eventID = smua.trigger.SWEEPING_EVENT_ID
eventID
Details
Set the stimulus of any trigger object to the value of this constant to have the trigger object respond to
sweeping events from this SMU.
2651A-901-01 Rev. C October 2021
Affected by Where saved
The sweep complete event number
Affected by Where saved
The sweeping event number
Section 7: TSP command reference
Default value
Default value
7-309
