Model 2651A High Power System SourceMeter® Instrument Reference Manual
status.standard.*
These attributes manage the standard event status register set of the status model.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
standardRegister = status.standard.condition
standardRegister = status.standard.enable
standardRegister = status.standard.event
standardRegister = status.standard.ntr
standardRegister = status.standard.ptr
status.standard.enable = standardRegister
status.standard.ntr = standardRegister
status.standard.ptr = standardRegister
standardRegister
Details
These attributes are used to read or write to the standard event status registers. Reading a status
register returns a value. The binary equivalent of the returned value indicates which register bits are
set. The least significant bit of the binary number is bit B0, and the most significant bit is bit B15. For
example, if a value of 1.29000e+02 (which is 129) is read as the value of the condition register, the
binary equivalent is 0000 0000 1000 0001. This value indicates that bit B0 and bit B7 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 15-1) and
this register are defined in the following table.
2651A-901-01 Rev. C October 2021
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
The status of the standard event status register; a zero (0) indicates no bits set (also
send 0 to clear all bits); other values indicate various bit settings
B13 B12 B11 B10
> > > >
0 0 0 0
Enable and transition registers
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
B9 B8 B7 B6 B5
> > > >
0 0 1 0
(on page 15-19). The individual bits of
Section 7: TSP command reference
Default value
- -
Not applicable
0
0
0
253 (All bits set)
B4 B3 B2 B1
> > > > >
0 0 0 0 0
Status register set
B0
*
1
