Model 2651A High Power System SourceMeter® Instrument Reference Manual
status.operation.user.*
These attributes manage the operation status user register set of the status model.
Type TSP-Link accessible
Attribute - -
.condition (RW) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
operationRegister = status.operation.user.condition
operationRegister = status.operation.user.enable
operationRegister = status.operation.user.event
operationRegister = status.operation.user.ntr
operationRegister = status.operation.user.ptr
status.operation.user.condition = operationRegister
status.operation.user.enable = operationRegister
status.operation.user.ntr = operationRegister
status.operation.user.ptr = operationRegister
operationRegister
Details
These attributes are used to read or write to the operation status user registers. Reading a status
register returns a value. The binary equivalent of the value indicates which register bits are set. In the
binary equivalent, the least significant bit is bit B0, and the most significant bit is bit B15. For example,
if a value of 1.29000e+02 (which is 129) is read as the value of the condition register, the binary
equivalent is 0000 0000 1000 0001. This value indicates that bits B0 and B7 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 15-1) and
this register are defined in the following table.
2651A-901-01 Rev. C October 2021
Affected by
- -
Status reset
Status reset
Status reset
Status reset
Status reset
B13 B12 B11 B10
> > > >
0 0 0 0
Enable and transition registers
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
The status of the operation status user register; a zero (0)
indicates no bits set (also send 0 to clear all bits); other values
indicate various bit settings
B9 B8 B7 B6 B5
> > > >
0 0 1 0
(on page 15-19). The individual bits of
Section 7: TSP command reference
Default value
- -
0
0
0
0
32,767 (All bits set)
B4 B3 B2 B1
> > > > >
0 0 0 0 0
Status register set
B0
*
1
