Section 2: General operation
The following table contains descriptions of the main menu options and cross-references to related
information. To access a menu option, press the MENU key, turn the navigation wheel to move the
cursor to select an item, and press the navigation wheel.
Menu selection
SCRIPT
- LOAD
- SAVE
SETUP
- SAVE
- RECALL
- POWERON
GPIB
- ADDRESS
- ENABLE
LAN
- STATUS
- CONFIG
- APPLY_SETTINGS
- RESET
- ENABLE
RS232
- BAUD
- BITS
- PARITY
- FLOW-CTRL
- ENABLE
TSPLINK
- NODE
- RESET
UPGRADE
DISPLAY
- TEST
- NUMPAD
DIGOUT
- DIG-IO-OUTPUT
- WRITE-PROTECT
BEEPER
- ENABLE
- DISABLE
LINE-FREQ
- 50Hz
- 60Hz
AUTO
SYSTEM-INFO
- FIRMWARE
- SERIAL#
- CAL
- MEMORY-USAGE
RESET-PASSWORD
2-14
Model 2651A High Power System SourceMeter® Instrument Reference Manual
Description
Saves and recalls users scripts
Loads scripts into nonvolatile memory
Saves scripts
Saves and recalls user and factory setup options
Saves user setup options
Recalls user setup options
Sets the configuration used during startup
Configures the GPIB interface options
Configures the address for the GPIB interface
Enables and disables the GPIB interface
Configures the local area network (LAN)
Displays LAN connection status
Configures the LAN IP address and gateway
Applies changes made using the CONFIG menu
Restores the default settings
Enables and disables the LAN interface
Controls the options for the RS-232 interface
Sets the baud rate
Configures the number of bits
Sets the parity
Configures the flow control
Enables and disables the RS-232 interface
Configures the instrument in a TSP-Link
Selects the instrument node identifier
Resets the TSP-Link network
Upgrades the firmware from a USB flash drive
Accesses display functions
Runs the display test
Enables and disables the numeric keypad
Controls digital outputs
Selects the digital I/O values
Write-protects specific digital I/O lines
Controls the key beeps
Enables the key beeps
Disables the key beeps
Configures the line frequency
Sets the line frequency to 50 Hz
Sets the line frequency to 60 Hz
Enables automatic line frequency detection during
start up
Displays system information
Displays the version of firmware installed
Displays the serial number of the instrument
Displays the last calibration date
Displays the memory usage in kilobytes
Resets the system password
For more information, see:
Manage scripts
Saved setups (on page 2-42)
Remote communications interfaces
page 2-80), GPIB setup
Remote communications interfaces
page 2-80), LAN communications
page 2-81), LAN concepts and settings
(on page 2-81, on page 13-1)
Remote communications interfaces
page 2-80), RS-232 interface operation
(on page 2-90)
®
network TSP-Link system expansion interface
Upgrading the firmware
Front panel tests
See Numeric entry method in
value (on page 2-16)
Digital I/O (on page 3-92)
Beeper (on page 2-18)
Line frequency configuration
2-10)
System information
Password management
2651A-901-01 Rev. C October 2021
(on page 6-3)
(on
(on page 2-83)
(on
(on
(on
(on page 11-4)
(on page 11-2)
Setting a
(on page
(on page 2-11)
(on page 6-41)
