Bit Value
B0 Not used
status.measurement.instrument.SMUA
B1
B2-B15 Not used
As an example, to set bit B1 of the measurement event instrument summary enable register, set
status.measurement.instrument.enable = status.measurement.instrument.SMUA.
In addition to the above constant, measurementRegister can be set to the decimal equivalent of
the bit to set.
Example
status.measurement.instrument.enable =
status.measurement.instrument.SMUA
Also see
Measurement event registers
status.measurement.instrument.smuX.*
This attribute contains the registers of the measurement event SMU X summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
measurementRegister = status.measurement.instrument.smuX.condition
measurementRegister = status.measurement.instrument.smuX.enable
measurementRegister = status.measurement.instrument.smuX.event
measurementRegister = status.measurement.instrument.smuX.ntr
measurementRegister = status.measurement.instrument.smuX.ptr
status.measurement.instrument.smuX.enable = measurementRegister
status.measurement.instrument.smuX.ntr = measurementRegister
status.measurement.instrument.smuX.ptr = measurementRegister
measurementRegister
X
2651A-901-01 Rev. C October 2021
(on page 15-7)
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
The status of the instrument measurement status SMU X summary register; a
zero (0) indicates no bits set (also send 0 to clear all bits); other values indicate
various bit settings
Source-measure unit (SMU) channel (for example
status.measurement.instrument.smua.enable applies to SMU
channel A)
Section 7: TSP command reference
Description
Not applicable.
Set bit indicates one or more enabled bits of
the measurement event SMU A summary
register is set.
Bit B1 decimal value: 2
Binary value: 0000 0010
Not applicable.
Sets the SMU A bit of the
measurement event instrument
summary enable register using a
constant.
Default value
- -
Not applicable
0
0
0
387 (All bits set)
