HD2 IP55 High-ingress Protection Series
Function
code
P02.10
P02.15
P02.16
P02.17
P02.18
P02.19
P02.20
P02.21
Quadrature-axis inductance
P02.22
P02.23
P05.01–
P05.06
Switching between motor 1
P08.31
P12.00
P12.01
P12.02
P12.03
P12.04
Name
No-load current of
asynchronous motor 1
Rated power of
synchronous motor 1
Rated frequency of
synchronous motor 1
Number of pole pairs of
synchronous motor 1
Rated voltage of
synchronous motor 1
Rated current of
synchronous motor 1
Stator resistance of
synchronous motor 1
Direct-axis inductance of
synchronous motor 1
of synchronous motor 1
Counter-emf constant of
synchronous motor 1
Function of multi-function
digital input terminal (S1–
S4, HDIA, HDIB)
and motor 2
Type of motor 2
Rated power of
asynchronous motor 2
Rated frequency of
asynchronous motor 2
Rated speed of
asynchronous motor 2
Rated voltage of
asynchronous motor 2
Description
0.1–6553.5A
0.1–3000.0kW
0.01Hz–P00.03 (max. output frequency)
1–50
0–1200V
0.8–6000.0A
0.001–65.535Ω
0.01–655.35mH
0.01–655.35mH
0–10000
35: Motor 1 switches to motor 2
0x00–0x14
Ones: Switch-over channel
0: Switch over by terminal
1: Switch over
communication
2: Switch
PROFIBUS/CANopen/DeviceNet
3: Switch over
communication
4: Switch over by EtherCAT/PROFINET
communication
Tens: Motor switch-over during running
0: Disable switch-over during running
1: Enable switch-over during running
0: Asynchronous motor
1: Synchronous motor
0.1–3000.0kW
0.01Hz–P00.03 (max. output frequency)
1–36000rpm
0–1200V
-66-
Basic Operation Instructions
Default
value
Depend
on model
Depend
on model
50.00Hz
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
by Modbus
over by
by Ethernet
Depend
on model
50.00Hz
Depend
on model
2
300
/
00
0
