Summary of Contents for IMO JAGUAR CUB CM Series
- Page 1 SINGLE PHASE MICRO-VERTER 0.2 - 2.2KW Year Guarantee...
- Page 2 Applications Please seek the full instruction manual before installation. Specifications and Characteristics If in doubt please call IMO on 020 8452 6444 or Common Specifications visit our website on www.imopc.com Terminal Designation (Please refer to inside back...
- Page 3 • Complete with a PID control function which can Conformity to Low Voltage Directive optimise the flow rate of fans and pumps. The Jaguar CUB CM Series conforms to the Low Voltage Directive with EN50178. Conformity to EMC Directive Compact •...
- Page 4 JAGUAR CUB CM Easy operation and simple, wiring • Equipped with a large potentiometer (on the front of the inverter) which sets output frequency. • Control through various input signals: from 0 to 10V DC, from 0 to 5V DC, and from 4 to 20 mA.
- Page 5 APPLICATIONS JAGUAR CUB CM Controlling fans and pumps using variable speed to save energy The PID* control function lets the inverter optimally control air conditioning systems and various types of fans The CUBCM can also accurately control pump speeds. *Proportional, Integral, Derivative Conveyors Mixers Adjusting the conveyor speed according to cycle time.
- Page 6 *1) Inverter output capacity (kVA) at 220V. *2) Output voltage is proportional to the power supply voltage and cannot exceed the power supply voltage. *3) Current derating may be required in case of low impedance loads such as high frequency motor. *4) This value is calculated using IMO calculation method. (Refer to Technical Information). *5) When a power-factor correcting DC REACTOR is used.
- Page 7 Motor overload • Protects the motor after the inverter trips (running or stopping • Electronic thermal overload relay can be selected for standard motor or IMO inverter motor Stall prevention • Controls the output frequency to prevent (overcurrent) trip when the output current exceeds the limit value during acceleration •...
- Page 8 TERMINAL DESIGNATION Terminal functions Symbol Terminal name Function Remarks Func. code Main L1/L, L2/N Power input Connect 1-phase 200V power supply circuit U, V, W Inverter output Connect 3-phase induction motor P1, P(+) For DC REACTOR Connect the DC REACTOR (option) for power-factor correction or harmonic current reduction Earth Terminal for inverter chassis...
- Page 9 BASIC ELECTRICAL CONNECTIONS JAGUAR CUB CM Keypad panel operation The following diagram is for reference only. For detailed wiring diagrams, refer to the relevant instruction manual. Connect the inverter to the power supply and the motor. Then, Power supply turn on the power to enable variable-speed operation. Notes: 1-phase 200 to 240V 50/60Hz...
- Page 10 KEYPAD PANEL FUNCTIONS AND OPERATION Keypad panel Digital monitor Up/Down keys In Operation mode: Displays output In Operation mode: Increases or frequency,* or output current. decreases frequency (motor speed). In Stop mode: Displays the set In Program mode: Increases or frequency.
- Page 11 JAGUAR CUB CM The keypad panel modes are classified in the following 5 modes: Mode Program mode Program mode Stop mode Operation mode Trip mode (operation stopped) (during operation) Monitor, keys Monitor Displays the function Displays the function Displays the set Displays the output Displays the trip code or data code.
- Page 12 1: Output current – – 2: PID feedback value 3: DC link circuit voltage 30RY operation mode 0: The relay (30) excites on trip mode – – 1: The relay (30) excites on normal mode *Typical value of IMO standard 4-pole motor...
- Page 13 JAGUAR CUB CM The functions in the white boxes can be set while the inverter is running. Other functions must be set while the inverter is stopped. Extension terminal functions Function Unit Min. Factory Setting range Code Name unit setting X1-X3 X1 terminal function Selects from the following items...
- Page 14 PROTECTIVE FUNCTIONS Function Description Digital monitor Operation • The inverter stops when a short circuit or an During • Inverter output stops Overcurrent protection overcurrent due to an overload occurs on inverter acceleration • The motor coasts to a stop output side During •...
- Page 15 EXTERNAL DIMENSIONS JAGUAR CUB CM Fig. 1 Fig. 2 CUB CM20 CUB CM150 CUB CM40 CUB CM75 17.2 D3 149 (D) 4-5 6 TERMINAL 2 17.2 ELONGATED HOLE (M3.5) TERMINAL 2 2- 5 (M3.5) CUB CM CUB CM WARNING WARNING STOP STOP CAUTION...
- Page 16 Three-phase average voltage [V] (For improving input power-factor, reducing harmonics) • Used to reduce input harmonic current (correcting power-factor) • For the resultant effects, contact IMO. AC Reactor (ACR) Optional. May be fitted to compensate for long motor cables, or shock loads...
- Page 17 RFI75CM CUB CM150 RFI150CM 190 165 118 117 Inverter mount 4XM4 CUB CM220 RFI220CM 240 216 168 148 128 118 M5 Earth Stud Rail mounting External dimensions base 72.4 (Unit: mm) *Maybe subject to change, please consult IMO if required...
- Page 18 OPTIONS Name (type) Description Personal RS485 communication is optional on the CUB CM. Serial transmission protocol An optional card must be mounted on this control board. computer Items Specifications interface card Three types of option card: OPC-C11S-RSA, OPC-C11S-RSB, and OPC-C11S-RSC, are available depending on the applicable inverter. Physical level EIA RS-485 standard (Two-phase) The following operations are possible from personal computers,...
- Page 19 If a safety condition. Full credit will not be given if in IMO’s hazard could arise from the expected starting of the judgment the unit has been physically or motor, an interlock mechanism should be provided to electrically abused.
- Page 20 • IMO recommend that you use rubber coupling or anti- cables (under the influence of high-frequency current flowing into...
