Goodrive100-PV Series Solar Pump Inverter
Function
code
RO1 switch-off
P06.11
RO2 switch-on
P06.12
RO2 switch-off
P06.13

P07 group Human-machine interface

Function
code
P07.00
User password
Name
0.000–50.000s
delay
0.000–50.000s
delay
0.000–50.000s
delay
Name
0–65535
When you set the function code to a
non-zero number, password protection is
enabled.
If you set the function code to 00000, the
previous user password is cleared and
password protection is disabled.
After the user password is set and takes
effect, you cannot enter the parameter
menu if you enter an incorrect password.
Please remember your password and save
it in a secure place.
After you exit the function code editing
interface, the password protection function
is enabled within 1 minute. If password
protection
displayed when you press the PRG/ESC
key again to enter the function code editing
interface. You need to enter the correct user
password to enter the interface.
Note: Restoring the default values may
delete the user password. Exercise caution
before using this function.
Description
Description
is
enabled,
"0.0.0.0.0"
-34-
Function parameter list
Default Modify
10.000s
0.000s
0.000s
Default Modify
0
is
