Goodrive100-PV Series Solar Pump Inverter
Function
code
P06.04
RO2 output
Output terminal
P06.05
polarity
selection
RO1 switch-on
P06.10
Name
4: Jogging
5: Inverter in fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Zero-speed running
10: Upper limit frequency reached
11: Lower limit frequency reached
12: Ready for running
13: Pre-magnetizing
14: Overload prealarm
15: Underload prealarm
16: Simple PLC stage completed
17: Simple PLC cycle completed
18: Set count value reached
19: Defined count value reached
20: External fault is valid
21: Reserved
22: Running time reached
23: Modbus communication virtual terminal
output
24–26: Reserved
27: In weak light
28–29: Reserved
30: Switches to PV input mode
Used to set the polarity of output terminals.
When a bit is 0, the output terminal is
positive.
When a bit is 1, the output terminal is
negative.
Setting range: 0–F
0.000–50.000s
delay
Description
BIT1
BIT0
RO2
RO1
-33-
Function parameter list
Default Modify
○
5
○
0
○
10.000s
