Goodrive100-PV Series Solar Pump Inverter
Status indicator description:
Display state
Green LED flickering
Green LED on
Red LED on
The figure below shows the installation dimension drawing of the boost module.
A.2 GPRS module and monitoring APP
The pump inverter supports an optional GPRS module to implement remote monitoring, and
the GPRS module connects to the inverters through 485 communication. The running state of
the inverter can be monitored in real time on the APP in the mobile phone or web page.
Method for connecting the GPRS module to the inverter:
Figure A–3 Connection between the GPRS module and the inverter
For details, see the GPRS/GPS Adaptor Operation Manual which comes with the GPRS
module or contact the local INVT office. Provide the model and serial number of the product
you query about.
The boost module has been powered on, and the control
circuit is working.
The boost module is running.
The boost module is faulty.
170
85
RUN
FAULT
FAULT
Figure A–2 Installation dimensions of the boost module
24V
COM
GD100-
PV
485+
inverter
485-
Description
24V
GND
GPRS
A
module
B
-59-
117
Antenn
a
Options
